The micro-flow regulating valve is a product independently developed by BAHE based on their original technology, specifically for ultra-small flow conditions. The valve body is small in size and light in weight. It can be designed in various connection methods such as threaded, welded, socket, and flange, facilitating installation and disassembly. Overall, it features a small size, light weight, high performance, and the ability to accurately control micro-flow. When regulating non-clean media, attention should be paid to preventing blockage and jamming due to the small throttling gap. It is specially tailored for ultra-small flow conditions, and the valve body is forged, making it easy to be made into a high-pressure structure. The size of the valve core can range from a processing tolerance of 1.5mm to 15mm, and is widely used in industrial process automatic control systems in industries such as power, petroleum, chemical, metallurgy, environmental protection, light industry, teaching, and research equipment for the main flow regulation of liquids, gases, and steam.
● The design adopts a top-guided type.
● The compact and lightweight design reduces the cost of installing pipes.
● High-quality SS316 austenitic stainless steel valve inner components material
● Optional SS416 stainless steel valve internals
● The dual-guided structure of the valve stem and the valve core enhances the stability of the valve core during its movement.
● It can provide multiple levels of valve internal component capacity reduction to meet different process requirements.
● It can be continuously adjusted within a small opening range.
● Adopting a top-guiding structure, it is resistant to vibration.
● The valve core adopts conical surface sealing, ensuring excellent sealing performance.
● The valve core adopts a diversified design, ensuring excellent adjustment performance.
● The valve core and valve seat are sprayed with hard alloy, which is resistant to erosion and has a long service life.
● Compact in size, lightweight and easy to install
● Electrical actuators can be installed interchangeably
● Key operating conditions: Low flow rate, High precision, Corrosive nature, Research and teaching purposes
● Traffic characteristics: Percentage, Linear characteristics
● Optional materials: F304, F316, F316L
● Valve size: DN8 - 25mm; NPS1/4"~1"
● Valve core size: DN3 to 25mm (CV: 0.0005 to 10)
● Pressure rating: PN1.0 - 42.0 MPa; CL150~2500
● Temperature range: -196 to +550℃ (optional for industrial and mining applications)
● Process connection: Flange, welding, thread, optional customization
● Gasket: Enhanced Teflon gasket, metal graphite gasket, high-pressure toothed gasket
● Filler material: Polytetrafluoroethylene, Flexible Graphite
● Actuators: Pneumatic actuators, Electric actuators
● Other configurations: Contact the BAHE business personnel or the technical department to obtain more technical specifications or option information about this product.
