Our low-load ventilation butterfly valve has a midline structure for the valve body. It is made by bending steel plates and welding them to the flange plates. It adopts an external bearing structure to reduce the resistance during valve opening and closing. The valve plate has no friction when closed, and the torque is small. It is suitable for switching and flow regulation in ventilation systems, air conditioning systems, and high-temperature smoke gases. Low-load butterfly valves are generally used in pipelines for ventilation and to regulate the flow of media in industries such as metallurgy, environmental protection, petrochemicals, power, building materials, and mining.
● Axial structure, high reliability
● The flow rate remains constant in a straight line, and the adjustment performance is excellent.
● The leakage rate can reach 0.5% to 3%.
● Simple structure, reliable performance
● 90° rotating structure, opening is quick
● Light in weight, quick to open and close, with low operating torque
● Easy to operate, labor-saving and agile.
● Pipe diameter range: DN50 to DN100
● Pressure range: 0.6 MPa
● Temperature range: -40℃ to +425℃ (customizable for high temperature)
● Material options: carbon steel, stainless steel, chromium-molybdenum steel, alloy steel.
● Sealing material: Hard seal
● Connection method: Socket type, Flange type (GB, ANSI, JIS, DIN)
● Driving method: Pneumatic actuator, Electric actuator, Worm gear and worm wheel
● Control mode: Switch type, Adjustable type
● Other configurations: Contact the BAHE business personnel or the technical department to obtain more technical specifications or option information about this product.
